JX Servo/BLS-HV7032MG/32KG High Torque Metal Gear Full CN High Voltage Brushless Digital Servo For RC Helicopter Drone Accessories

JX Servo/BLS-HV7032MG/32KG High Torque Metal Gear Full CN High Voltage Brushless Digital Servo For RC Helicopter Drone Accessories Item NO.: F44003

Write a Review
US$ 40.00
US$ 43.96 Save US$ 3.96 (9% Off)
Quantity

Copy and share this link on social network or send it to your friends

Copy
  • JX Servo/BLS-HV7032MG/32KG High Torque Metal Gear Full CN High Voltage Brushless Digital Servo For RC Helicopter Drone Accessories
Product Name JX Servo/BLS-HV7032MG/32KG High Torque Metal Gear Full CN High Voltage Brushless Digital Servo For RC Helicopter Drone Accessories
Item NO. F44003
Weight 0.045 kg = 0.0992 lb = 1.5873 oz
Category DIY RC Drone Accessories > Servo
Brand JX
Creation Time 2021-06-18

JX Servo/BLS-HV7032MG/32KG High Torque Metal Gear Full CN High Voltage Brushless Digital Servo For RC Helicopter Drone Accessories

Feature:
-High-performance high-pressure brushless digital standard steering gear
-Hard anodized high-precision aluminum gear made in Taiwan
-High performance brushless motor
-Full CNC structure shell
-Double ball bearing
-With waterproof ring

Detailed specifications:
Dead zone: 1μs
Working frequency: 1520μs/330hz
Motor: Brushless
Speed (6.0V): 0.09 seconds/60°
Speed (8.4V): 0.07 seconds/60°
Torque (6.0V): 26.3 kg.cm (364.96oz/in)
Torque (8.4V): 32.51 kg-cm (451.18 ounces/inch)
Size: 40.5X20.5X36mm/1.59X0.80X1.43in
Weight: 70.1 grams (2.47 ounces)
Connection cable: JR 265 mm (10.43 inches)
Bearing: 2BB
Shelf life: three months

Include
Servo accessories package
Steering arm
