Copy| Product Name | FlySky FS-CEV04 FS-CPD01 FS-CPD02 FS-CTM01 CVT01 Temperature Telemetry Data Module for FS i10 iT4S TX iA4B iA10B RX iBus |
| Item NO. | F39213 F39214 F39215 F39216 F39217 F39218 |
| Weight | 0.05 kg = 0.1102 lb = 1.7637 oz |
| Category | DIY RC Drone Accessories > Receiver |
| Brand | Flysky |
| Creation Time | 2020-07-16 |
FlySky FS-CEV04 FS-CPD01 FS-CPD02 FS-CTM01 CVT01 Temperature Telemetry Data Module for FS i10 iT4S TX iA4B iA10B RX iBus
Flysky AFHDS2A TELEMETRY Module Set (FS-CEV04, FS-CPD01, FS-CPD02, FS-CTM01, FS-CVT01)
Compatible Receiver: iA4B(directly), iA10(need conversion cable)
MODEL: FS-CPD01 RPM Telemetry [magnetic] module
Monitor range of speed 60000RPM/mins
Power: 4.0-6.5V DC
Weight: 6.6g
Size: 31*15*8.5mm
MODEL: FS-CPD02 RPM Telemetry [Photo Induction(optical)] module
Monitor range of speed 60000RPM/mins
Power: 4.0-6.5V DC
Weight: 6.8g
Size: 31*15*8.5mm
MODEL: FS-CTM01 Temperature acquisition module
Monitor range of temperature: -40-250°C
Power: 4.0-6.5V DC
Weight: 6.8g
Size: 31*15*8.5mm
MODEL: FS-CVT01 Voltage acquisition module
Monitor range of Voltage: 0-100V DC
Power: 4.0-6.5V DC
Weight: 6g
Size: 31*15*8.5mm
MODEL: FS-CEV04 i-BUS Serial bus receiver
Channels: 4
Weight: 8.1g
Power: 4.0-6.5V DC
Size: 30*25.6*13mm
i-BUS PORT: yes
