RadioLink R9DS 9CH 9 Channel Receiver 2.4Ghz For AT10 AT9 Transmitter Aircraft Aerial Photography Device

RadioLink R9DS 9CH 9 Channel Receiver 2.4Ghz For AT10 AT9 Transmitter Aircraft Aerial Photography Device Item NO.: F10491

Write a Review
US$ 18.39
US$ 19.99 Save US$ 1.60 (8% Off)
Customized Requirements
Quantity

Copy and share this link on social network or send it to your friends

Copy
Product Name RadioLink R9DS 9CH 9 Channel Receiver 2.4Ghz For AT10 AT9 Transmitter Aircraft Aerial Photography Device
Item NO. F10491
Weight 0.0385 kg = 0.0849 lb = 1.3580 oz
Category DIY RC Drone Accessories > Receiver
Brand RadioLink
Creation Time 2017-07-25

RadioLink R9DS 9CH 9 Channel Receiver 2.4Ghz For AT10 AT9 Transmitter Aircraft Aerial Photography Device

 Product feature

DSSS /3ms Top speed response /4096 Resolution/ HV support/S.BUS

Compatible with TX :  AT10 and AT9

 Bind

 When you use the R9D, you need to bind. After binding finished, you don't need to bind again in the second time use. Power on the transmitter and receiver, press and hold the binding key for one second till the red LED starts flashing. When it keeps red, it means binding is finished.

S.BUS setting:

CH9 is usually used for PWM or S.BUS. The blue LED means S.BUS output and red means PWM. Short press binding key two times within one second to change output from PWM to S.BUS.


3

Two kinds of color random delivery,if you have specific requirements ,please leave a message

IMG_7636IMG_7637IMG_7638IMG_7639IMG_7640IMG_7641
