FEICHAO 6354-180KV Dustproof Brushless High Power For Four-wheel Remote Control Skateboard Motor
Product Description
Name: N6354S
Body diameter: 63mm
Shaft diameter: 10mm
Body height: 60mm
Flat thickness: 9mm
Flat length: 20mm
Output shaft length: 30mm
Top mounting hole distance: 30mm
Bottom mounting hole distance: 20mm
Mounting hole size: M4*4
Banana head: 4.0/3.5
Weight: 595g
Maximum power: 1820W
Hall angle: 60
No-load current: 0.8-1.7A
Maximum current: 80A
Recommended voltage: 24-36V
KV value: 170-330KV
No-load speed: 3600-5800rpm
Torque: 1.9-2.6N/m
No-load speed = voltage * KV value
As the KV value increases, the speed increases, and the torque decreases; when the KV value decreases, the speed decreases, and the torque increases.
