Skyzone FT24 2.4GHz 12CH 15KM Long Range Transmitter Remote Controller for DIY FPV Drone R9M/TBS Multi-protocol RF w/ FR/FR Mini OTA Receiver

Skyzone FT24 2.4GHz 12CH 15KM Long Range Transmitter Remote Controller for DIY FPV Drone R9M/TBS Multi-protocol RF w/ FR/FR Mini OTA Receiver Item NO.: F42181-D1 F42181-D2 F42181-D3 F42181-D4 F42181-D5 F42181-D6

Write a Review
US$ 84.14
US$ 98.99 Save US$ 14.85 (15% Off)
Version
Left Right
Type
No Receiver With FR Receiver With FR Mini Receiver
Quantity

Copy and share this link on social network or send it to your friends

Copy
Product Name Skyzone FT24 2.4GHz 12CH 15KM Long Range Transmitter Remote Controller for DIY FPV Drone R9M/TBS Multi-protocol RF w/ FR/FR Mini OTA Receiver
Item NO. F42181-D1 F42181-D2 F42181-D3 F42181-D4 F42181-D5 F42181-D6
Weight 0.45 kg = 0.9921 lb = 15.8733 oz
Category DIY RC Drone Accessories > Remote Control
Brand Other Brands
Creation Time 2020-11-25

Skyzone FT24 2.4GHz 12CH 15KM Long Range Transmitter Remote Controller for DIY FPV Drone R9M/TBS Multi-protocol RF w/ FR/FR Mini OTA Receiver


Description:
Brand Name: SIYI
Item Name: FT24 Transmitter with Receiver (Optional)
Weight: 586g (without battery)
Size: 191*175*64mm
Maximum communication distance (no interference, no obstruction): 15 KM
Operating frequency: 2.400-2.483 GHz
Output: PPM/PWM/SBUS
Number of channels: 12 physical channels, 16 signal channels
Support models: multi-rotor/fixed-wing/glider/helicopter/car/ship
Support battery type: 18650 *2, 2S Lipo battery (Not Include)
Battery compartment size: 60*58*16 MM
Antenna gain: 2dbi
Working current (rated): 210mA

Receiver:
FR Receiver FR Mini Receiver
Signal output: 16-channel S.Bus, 8-channel PPM, 8-channel PWM Signal output: 16-channel S.Bus, 8-channel PPM
Data interface: UART Data interface: UART
Size (without antenna): 51.5*38*13mm Size (without antenna): 24*15*3mm
Weight (without antenna): 20g Weight (without antenna): 1.5g
Antenna gain: 2dbi Antenna gain: 2dbi
Operating voltage range: 5V-8.4V Operating voltage range: 5V
Return voltage range: 0-50V Return voltage range: 0-26V
Working environment temperature: -10℃ to 55℃ Working environment temperature: -10℃ to 55℃

Featrues:
15KM long-distance flight
Expand Bluetooth, FPV, Link
Chinese and English custom voice broadcast
Telemetry data return
OTA wireless upgrade receiver
Support TF card
Bearing assembly Gimbal
4096 high resolution ratio channels
2MS high-speed response
2.8 inch high brightness color LCD screen
Chinese and English menu
Power voltage, RSSI signal return

Package Included:
1 x FT24 Transmitter
1 x FR Receiver (Optional)
1 x FR Mini Receiver (Optional)
