Copy| Product Name | LD2411 24G Radar Sensor Module Smart Home Human Distance Sensing & Gesture Recognition Module Automatic Switch FMC W Modulation |
| Item NO. | F51148 |
| Weight | 0.015 kg = 0.0331 lb = 0.5291 oz |
| Category | Consumer Electronics > Smart Switch |
| Creation Time | 2023-11-09 |
Product Description
LD 2411 is a 24GHz radar sensor module for smart home and bathroom applications.
The working principle is to use FMC W FM continuous wave to detect the human target in the set space.
Combined with radar signal processing, accurate human body sensing algorithms,
it senses the state of moving objects approaching and moving away, as well as human gesture recognition.
and human gesture recognition.
Mainly applied to smart toilets, sensing whether someone is approaching/away within 2 metres of the sensing area.
Gesture action recognition within 0.5-1 metre, and real-time output of high and low level signals.
Configuration tools are available to modify the sensing distance range, sensing sensitivity and unoccupied delay time.
Product Features
-Frequency: 24.015G-24.245GHz
-Modulation: FMC W
-Detection distance: 0.3~2.2m adjustable
-Detection Angle: ±45°(Horizontal plane)/±20°(Vertical plane)
-Power supply: 5V(Typ.)
-Current: ~50mA
-Maximum equivalent omni-directional radiated power: 12dBM (Typ.)
-Sweep bandwidth: 230MHz (CE/FCC compliant)
-Ambient Temperature: -40°C~+85°C
-Data format: High and low level 3.3V&0V
-Package: Default 1.27mm*5Pin female socket
Interface Type: (1.27mm×5PIN Pin)
1: VCC, 5V power supply input
2: GND, power supply ground
3: OUT, output high level
4: TXD, Serial Transmit/IO
5: RXD, serial port receive/IO
Module installation method, toilet application, it is recommended that the horizontal narrow beam,
in order to avoid false triggering next to the passing human body.
Toilet lid ring for 5 states: unoccupied state (default lid ring closed),
people to open the lid (under the state of closed lid),
Gesture flip ring (under open lid state),
person walks to close the lid (under open lid state)
and person walks to close the ring to close the lid (under open lid ring state).
