HI-LINK 24G Water Level Detection Sensor Radar Module Liquid Detection Non-contact Induction Switch LD2413 Item NO.: F53089-D1 F53089-D2

US$ 14.42 ~ US$ 16.02

Quantity	0-3	4-50	51-100
Discount	0% OFF	5% OFF	10% OFF
Price	US$ 16.02	US$ 15.22	US$ 14.42

Color

Quantity: Stock ( 19999998 )

Estimate Shipping Cost

Product Name	HI-LINK 24G Water Level Detection Sensor Radar Module Liquid Detection Non-contact Induction Switch LD2413
Item NO.	F53089-D1 F53089-D2
Weight	0.015 kg = 0.0331 lb = 0.5291 oz
Category	Consumer Electronics
Creation Time	2024-09-09

HI-LINK 24G Water Level Detection Sensor Radar Module Liquid Detection Non-contact Induction Switch LD2413

Product parameters
Frequency: 24GHz (23-27GHz)
Modulation method: FMCW
Scanning bandwidth: 4GHz
Detection distance: 0.15m~10m
EIRP parameter: 11dBm (-6dB two-way)
Horizontal/vertical range: ± 12 °
Distance measurement accuracy: ± 3mm (theoretical value)
Reporting cycle: 160ms (50~1000ms/configurable)
Environmental temperature: -40 ℃~+85 ℃
Package size: 31.6 * 51.6 * 2.2mm
Power supply range: 3.3V (3.0~3.6V) @ 1A
