FLP9p-100MHz 9-order Low-pass Filter SMA Interface Discrete LC Components With Small Volume
-
Detail
- Product Name: FLP9p-100MHz 9-order Low-pass Filter SMA Interface Discrete LC Components With Small Volume
- Item NO.: F51052
- Weight: 0.025 kg = 0.0551 lb = 0.8818 oz
- Category: DIY RC Drone Accessories
- Creation Time: 2023-11-02
FLP9p-100MHz 9-order low-pass filter SMA interface discrete LC components with small volume
Characteristics:
Small volume, flat passband, high out of band suppression
Aplication:
Laboratory Applications
Other highly selective applications
Model: FLP9p-100
Impedance: 50 Ohms
Insertion loss: <=1dB @<80MHz
≈ 2.0dB @ 100MHz
>50dB @ 200-2000MHz
Maximum carrying capacity: 1 W (30 dBm)
Interface: SMA-M, SMA-F
Frequency response chart: (Sweep frequency range: 40-1000MHz, blue line represents transmission loss, vertical scale 10dB per grid. Yellow line represents reflection loss, vertical scale 5dB per grid)
