Copy| Product Name | BETAFPV Pavo Pico Brushless Bwhoop Drone F4 12A AIO Brushless Flight Controller V3 1102 14000kv Brushless Motor FPV Quadcopter |
| Item NO. | F50218-D1234 |
| Weight | 0.225 kg = 0.4960 lb = 7.9366 oz |
| Category | DIY RC Drone Accessories |
| Brand | BETAFPV |
| Creation Time | 2023-06-05 |
Note: 1. The package picture above is the For DJI O3 HD digital VTX version. 2. For DJI O3 HD Digital VTX, Avatar HD Digital VTX, and Vista HD Digital VTX are not included in all packages. You need to buy it yourself.
Thanks to all the enthusiastic pilots who participated in the BETA TEST before, we've now released the smallest 2S Sub100g For DJI O3 Cinewhoop! This ultra-light cinewhoop with a small wheelbase is not only equipped with 45mm propellers but the latest F4 1S 12A AIO Brushless FC V3 which greatly heightens the flying experience. Due to Its split design HD VTX mounting bracket, it supports quick installation of mainstream HD digital VTX modules and a rubber damper vibration-damping design with GyroFlow stabilization software ensures stable and smooth HD images. Its design is well-suited for cruising indoors and outdoors alike.
Note: The Camera and HD Digital VTX(For DJI O3 HD Digital VTX, Walksnail Avatar HD Digital VTX, and Vista HD Digital VTX) are not included in all packages. you need to buy them separately.
Note: The flight time is calculated under 8.4V~6.8V. And the Pavo Pico Brushless Whoop Quadcopter does not include HD VTX and Camera.
Pavo Pico supports various types of HD VTX.For DJI O3 and Walksnail Avatar Pro Kit both support HD digital VTX up to 1080P using dual-band transmission technology for better signal stability. The Vista Kit supports digital signal transmission for HD video up to 720P, with low latency and superior image quality performance. It's compact and lightweight, making it great for small drone installation, and compatible with various remote controls and monitors. The customized HD VTX mounting bracket has a split design, making it effortless to install for pilots DIY, and explore more possibilities while ensuring HD image quality.
BETAFPV ND Filter for DJI O3 Camera is specifically designed for the Pavo Pico Brushless Whoop Quadcopter. Meanwhile, the For DJI O3 Air Unit ND Filters are tailored for the For DJI O3 Air Unit and are capable of reducing the amount of light that enters the camera lens. With this feature, you can achieve slower shutter speeds or wider apertures when flying. These lightweight filters are crafted from high-quality optical class ensuring optimal image clarity and are too easy to install on the build.
We used ultra-light PP material to make the HD VTX mounting bracket, increasing its toughness. The antenna fixing slot and frame have been fused to reduce damage risk, while the camera's installation height has been lowered with a protective printed part to limit its movable angle to within 30°. Additionally, an O3 filter can be used to protect the lens and enhance image quality. We have incorporated a unique rubber damper vibration-damping design, used with GyroFlow stabilization software, which greatly enhances safety and ensures a smooth, HD image output. When you screw the die-cast screws, please DO NOT screw them too tight to leave room for rubber dampers to absorb vibration. It may cause jello in the video footage.
Click to watch the installation guide video for DJI O3 Air Unit on Pavo Pico.
And The whoop quadcopter package includes the For DJI O3 HD Digital VTX Antenna Mount.
After collecting feedback through the BETA TEST, we lowered the height of the HD VTX mounting bracket and whoop duct from 60.6mm to 51.5mm and the battery compartment results in a more low profile on the cinewhoop. Pilots can further customize their cinewhoop with DIY options such as battery straps or printable components, allowing for compatibility with a variety of battery sizes. This enables pilots to tailor and enhance their cinewhoop to meet their specific requirements and preferences.
F4 1S 12A AIO Brushless FC V3, the FIRST flight controller designed specifically for HD VTX. This whoop quadcopter is equipped with STM32F405 chip for high-performance calculations. It weighs only 4.2 grams and includes a Serial ELRS 2.4G receiver, 16MB Black Box, Barometer, and Current meter. Designed for HD VTX, it also added support for external GPS through Betaflight 4.4.0
The 1102 14000kv motor brings stronger power and lower noise, delivering abundant thrust and impressive speed that enable effortless execution of aerial maneuvers. Paired with the high-performance Gemfan 45mm propeller, this power system achieves superb balance, ensuring powerful lift and stable flight, while also providing precise and responsive control. The combination of these power systems makes it an excellent choice for Pavo Pico, allowing pilots to easily accomplish filming tasks.
We found that the installation dimensions of the Vista and Avatar HD Pro digital VTX modules closely match those of the O3 digital VTX. Thus, Installing a carbon plate with mounting holes that measure 20x20mm is sufficient to mount both digital VTXs. Install quickly and effortlessly, while meeting pilots' various DIY needs, and exploring more possibilities for flying.
BETAFPV has been dedicated to enhancing the performance of the Pavo Cinewhoop Series through continuous optimization and upgrades. The Pavo Cinewhoop Series including Pavo25, Pavo30, and Pavo360, is designed to deliver exceptional results when it comes to capturing breathtaking and seamless footage. Additionally, these drones offer pilots an exhilarating flight experience that's bound to satisfy their cravings for adventure.
