FEICHAO 60KG Digital Servo High Torque 6v-8.4v Waterproof Metal Gear Servo for 1/5 RC Cars, Compatible with Futaba JR SANWA Hitec Jumper Flysky Frsky TX

Copy and share this link on social network or send it to your friends

Copy

FEICHAO 60KG Digital Servo High Torque 6v-8.4v Waterproof Metal Gear Servo for 1/5 RC Cars, Compatible with Futaba JR SANWA Hitec Jumper Flysky Frsky TX Item NO.: F43342 F43343 F43344

Write a Review
US$ 15.47 (8% Off)
US$ 16.81 Save US$ 1.34
Version:
180° 270° 360°
Quantity:
Shipping Cost:
Estimate Shipping Cost

Product Name FEICHAO 60KG Digital Servo High Torque 6v-8.4v Waterproof Metal Gear Servo for 1/5 RC Cars, Compatible with Futaba JR SANWA Hitec Jumper Flysky Frsky TX
Item NO. F43342 F43343 F43344
Weight 0.195 kg = 0.4299 lb = 6.8784 oz
Category Toy and Hobbies > Servo
Brand FEICHAO
Creation Time 2021-03-23

FEICHAO 60KG Digital Servo High Torque 6v-8.4v Waterproof Metal Gear Servo for 1/5 RC Cars, Compatible with Futaba JR SANWA Hitec Jumper Flysky Frsky TX


Brand: FEICHAO
Products Name: 60kg Digital Servo
Color: Black + Red
Specification: 180 ° / 270 ° / 360 ° (optional)
Size: 82 * 48 * 29.9mm
Weight: 162g (excluding accessories)
The best voltage is 7.4v. It is recommended to use 2S battery power supply (6v-8.4v)

Features:
High performance programmable digital standard steering gear,
It can be widely used in robots, robot arms, mountain car and remote control toys.
Fast heat dissipation
High torque
Strong compatibility
Responsive, etc.
Compatible with Futaba, Jr, Sanwa, HITEC, jumper, FlySky, frsky, etc. RC Transmitter

- Each Pack include:
Steering gear * 1
Accessory Pack * 1

Products Specifcation:
Apply Environmental Conditon
Storage Temperature Range: -30°C~80°C
Operating Temperature Range: -25°C~70°C

Standard Test Environment
Temperature Range:    -25°C~70°C
Humidity Range: 65%±10%

Mechanical Specification
Size: 40.0*20.0*37.5mm
Weight: 158g±5%
Gear type: 6 Metal
Limit angle: 360°
Bearing: 2BB
Horn gear spline: 18T    Diameter:8.1mm
Horn type: Plastic, POM
Case: Engineering plastics(PBT)+Aluminum alloy
Connector wire: 320mm±5mm
Motor: Carbon brush motor
Splash water resistance

Electrical Specification
Operat voltage: 6V;8.4V
Idle current: 5mA; 5mA
No load speed: 0.17sec/60°;0.13sec/60°
Runnig current: 400mA;510mA
Peak stall torque: 58.5kg.cm;70kg.cm
Stall current: 8.5A±10%;10.4A±10%
Working voltage range: 4.8-8.4V

Control Specification
Command signal: Pulse width modification
Amplifier type: Digital controller
Pulse width range: 500~2500usec
Neutral position: 1500usec
Running degree: 180°±3°(when 500~2500usec)
Dead band width: 5usec
Rotating direction: Counterclockwise (when 1000~2000usec)
