CC2500 Wireless Data Transmission Module Integrated PA+LNA Chip Wireless Remote Control Module 2.4G Wireless Transceiver Item NO.: F46770

CC2500 Wireless Data Transmission Module Integrated PA+LNA Chip Wireless Remote Control Module 2.4G Wireless Transceiver

Characteristic
SPI interface
High cost performance
2.4GHz band
Built-in high power PA/LNA chip, direct up to 23dBm, directly solve the problem of 2.4G communication distance close.
Die pack (bare die)
long range communication
Digital RSSI Support
Support Manchester Coding
anti-interference
Global license-free 2.4GHz band, support adjustable band range: 2.400-2.483GHz
Support software setting power, maximum support 23dBm.
Support software rate regulation, maximum support 500kbps.
Support FSK,GFSK,MSK ASK and OOK?
Integrated IPEX seat and external antenna interface, use more flexible and more stable signal, communication without dead spots.

Parameters
Chip: CC2500
Operating frequency band: 2.4GHz
Maximum output power: 20dBm
Receive Sensitivity: -112dBm@2.4kbps
Transmission current: <300mA
Receive current: <25mA
Module size: 31.6*16.5mm
Antenna interface: external antenna / IPEX seat
Distance: 800m
Q&A
Q: What is the SPI hardware module?
A: The SPI wireless module is a pure hardware wireless module, its interface uses SPI universal mode, it needs external MCU connection. MCU programming to set the module chip register parameters to complete data communication.
