(BETAFPV）Meteor75 Pro II Brushless Whoop Frame For replacing drone accessories

US$ 4.99

Color

Estimate Shipping Cost

Detail

Product Name: (BETAFPV）Meteor75 Pro II Brushless Whoop Frame For replacing drone accessories
Item NO.: F55691-A1 A2 A3 A4 A5
Weight: 0.016 kg = 0.0353 lb = 0.5644 oz
Category: DIY RC Drone Accessories > Frame
Brand: BETAFPV
Creation Time: 2026-07-13

(BETAFPV）Meteor75 Pro II Brushless Whoop Frame For replacing drone accessories

(BETAFPV）Meteor75 Pro II Brushless Whoop Frame For replacing drone accessories

The Meteor75 Pro II Frame is a next-generation whoop frame designed for superior flight performance, durability, and ease of use. Featuring optimized aerodynamics with arm braces refined from 6 to 5 and a curved whoop duct design, it reduces weight and air resistance for improved flight efficiency. With simplified installation through four shock-absorbing mounting holes and seamless Canopy II compatibility, the frame delivers stable, jello-free footage and effortless maintenance. Weighing only 5.80g—nearly 2g lighter than the previous version—and built tough to withstand crashes, the Meteor75 Pro II Frame offers an agile flying experience and exceptional durability, making it the ideal choice for both indoor and outdoor flights.

Meteor75 Pro II Brushless Whoop Frame

Bullet Points

Optimized Derodynamics: Arm braces refined from 6 to 5 and curved whoop duct reducing weight and air resistance for improved flight efficiency.
Simplified Installation: Four shock-absorbing mounting holes with Canopy II compatibility ensure easy assembly, quick maintenance, and stable footage.
Lightweight Design: Weighing only 5.80g—nearly 2g lighter than the previous version—for a more responsive and agile flight experience.
Exceptional Durability: Built tough to withstand crashes, so you can get back in the air quickly and keep flying with confidence.

Specifications

Item: Meteor75 Pro II Brushless Whoop Frame
Material: PP
Wheelbase: 80mm
Weight: 5.80g
Color: Transparent gray, black, white, blue, purple
Motor Mounting Hole: 3-M1.4-φ6.6mm
FC Mounting Hole: 26*26mm
Battery Slot: 16.1*6.3mm
Dimensions: 108.5*108.5*16.2mm

Diagram

Meteor75 Pro II Brushless Whoop Frame diagram

Optimized Aerodynamics

The arm braces have been refined from 6 to 5, reducing weight while maintaining structural integrity. The whoop duct has been aerodynamically optimized to minimize air resistance, resulting in improved flight efficiency and overall performance. With a total weight of only 5.80g—nearly 2g lighter than the previous version—it delivers a noticeably lighter and more responsive flight experience for Meteor75 Pro II.

Meteor75 Pro II Brushless Whoop Frame vs Meteor75 Pro Frame

Simple Installation & Unmatched Durability

Four new installation holes for shock-absorbing balls, paired with the Canopy II for O4 Air Unit, simplify both installation and removal while delivering stable, jello-free footage performance. This durable and low-maintenance design makes the Meteor75 Pro II Frame ideal for both indoor and outdoor flight environments.

Meteor65 Pro II Brushless Whoop Quadcopter vibration damping

Meteor75 Pro II Frame vs. Meteor75 Pro Frame

	Meteor75 Pro II Frame	Meteor75 Pro Frame
Wheelbase	80mm	80.8mm
Duct Diameter	47mm	47.9mm
Duct Height	4.8mm	5.8mm
Arm Braces	5	6
Screw Protection Structure	Supported	-
Motor Screws	M1.4*3mm	M1.4*4mm
Motor Fixed Slot	Supported
Propellers	45mm props
Battery Slot Size	16.1*6.3mm	16.7*6.3mm
Battery	LAVA II 1S 480mAh/580mAh/680mAh
Weight	5.80g	7.73g
