XT-XINTE PCIE to 2 Ports USB3.0 Expansion Card Desktop Front 19/20PIN Header Interface for PCI-E x1/x4/x8/x16 for Windows XP/7/8/8.1/10

XT-XINTE PCIE to 2 Ports USB3.0 Expansion Card Desktop Front 19/20PIN Header Interface for PCI-E x1/x4/x8/x16 for Windows XP/7/8/8.1/10 Item NO: F26821

US$ 6.24 (10% Off)
US$ 6.93 Save US$ 0.69
Remark:
Customized Requirements
Quantity:
Shipping Cost:
Estimate Shipping Cost
Specifications
Product Name XT-XINTE PCIE to 2 Ports USB3.0 Expansion Card Desktop Front 19/20PIN Header Interface for PCI-E x1/x4/x8/x16 for Windows XP/7/8/8.1/10
Item NO F26821
Weight 0.1000 kg = 0.2205 lb = 3.5274 oz
Category Consumer Electronics > Computer Cable and Adapter
Brand XT-XINTE
Creation time 2018-12-24

Detail

PCIE Transfer 2 Ports USB3.0 Expansion Card Desktop Front 19/20PIN Header Interface for PCI-E x1/x4/x8/x16 for Windows XP/7/8/8.1/10


Specification:

Type: 2 interfaces USB3.0 expansion card
Chipset: U3V14S
Interface:PCI-E X 1
Compatible PCI slot:X1-X4/x8/x16
USB interface:2 X USB3.0

Transfer Rate: 5 Gb/s USB3.0

Product size: 120X77X68mm

Applicable models:conventional desktop

Support system:Windows XP32/64 Windows 7(32/64)windows8/8.1 windows10

Support OS:
Windows XP 32/64
Windows 7 32/64
Windows8 (Support plug-and-play)
Windows8.1 (Support plug-and-play)
Windows10 (Support plug-and-play)


Driver Download:

VL Series Download:  http://file2.mydrivers.com/2014/board/via_usb3_4_90a_driver.zip
N Series Download:http://file2.mydrivers.com/others/renesas_usb_3.0.23.0.zip


Feature:

1.high speed operation core, high compatibility
2.The card comes with 2A power supply and do not need external power supply, 330 12X12mm inductor is better than 100 10X10mm one.
3.Each interface equips with independent interface protection fuse, and immediately cut off the power while external USB short circuit or overcurrent happens, protect external divices and computer from damage, automatically return to normal after troubleshooting
4.Each interface equips with independent regulated capacitor, guarantee smooth power supply without interface, also can undertake 250° celsius with Solid chip capacitor, strong endurance

5.With immersion gold process, good electrical conductivity, strong antioxidant capacity, it can guarantee stable transmission


Package included:
1 X Expansion Card

Note:
Please allow 1-3mm differs due to manual measurement.
Due to the different display and different light, the picture may not reflect the actual color of the item. Thanks for your understanding.
