Surpass Hobby New KK Waterproof Combo 3660 2600KV Brushless Motor w/Heat Sink 60A ESC Speed Controller for RC Car

Surpass Hobby New KK Waterproof Combo 3660 2600KV Brushless Motor w/Heat Sink 60A ESC Speed Controller for RC Car Item NO.: F43795

Write a Review
US$ 37.78
US$ 44.45 Save US$ 6.67 (15% Off)
Quantity

Copy and share this link on social network or send it to your friends

Copy
Product Name Surpass Hobby New KK Waterproof Combo 3660 2600KV Brushless Motor w/Heat Sink 60A ESC Speed Controller for RC Car
Item NO. F43795
Weight 0.4 kg = 0.8818 lb = 14.1096 oz
Category DIY RC Drone Accessories > Motor
Brand Surpass Hobby
Creation Time 2021-05-10

Surpass Hobby New KK Waterproof Combo 3660 2600KV Brushless Motor w/Heat Sink 60A ESC Speed Controller for RC Car


Features:
4 Pole 12 Slot Hi-torque Motor Design
High Quality: CNC Machined 6061 T6 Billet Aluminum Heatsink Can, High Purity Copper Windings Maximizes Efficiency, High RPM ABEC5 Oversized Bearings
Universal fit, for 1:10 2S RC car , 3S RC racing, off-road car
Precision balanced rotor,smoothness for best reliability and maximum RPM
Stator - Super Thin (0.35mm) Laminations

Specifications:
Brand: SURPASSHOBBY
Series: KK
Name: 3660 RC Motor
KV(RPM/Volt): 3100KV
Watt:1200
Max RPM: 50000
Max voltage: <12V
Max amps: 100A
Rotor poles: 4
Diameter: 35.5mm
Length: 59mm
Shaft length: 17mm
Connector: 4.0mm gold
Weight:218g

ESC DECLARATION:
This is Electronic Speed Controller (ESC) for car. High power system for RC model is very dangerous, so please read this manual carefully.
Since we can't control over the correct use, installation, application, or maintenance of our products, we'veno liability shall be assumed nor accepted for any damages,
losses or costs resulting from the use of the product. Any claimsarising from the operating, failure of malfunctioning etc. will be denied.
We assume no liability for personal injury,consequential damages resulting from our product or our workmanship.

ESC Features:
1. Water- proof and dust-proof for all-weather races; (Note: please uninstall the cooling fan before using this ESC in water;Clean and dry it soon after the use for avoiding the connectors get rusty.)
2. Specially designed for RC car with excellent start-up, acceleration and linearity features.
3. Compatible with sensorless brushless motor.
4. The strong resistant current capability, excellent heat dissipation.
5. Multiple protection features: Low voltage cut-off protection for litium or nickel battery /Over-heat protectionThrote signal loss protection / Motor blocked protection/
6. Easily programmed and compatible with pocket-sized program card.

Specification:
Brand: SURPASSHOBBY
Name: KK 60A ESC
Cont.Current/Burst Current: 60A/360A
Motor Type: Sensorless Brushless Motor

for 2S Lipo or 6 cells NiMH :
1. on-road: 3660-Size or smaller motor with the KV<6000KV
2. off-road/Buggy/Monster: 3660-size or smaller motor with the KV <4000KV

for 3S Lipo or 9 cells NiMH :
1. on-road: 3660-Size or smaller motor with the KV<4000KV
2. off-road/Buggy/Monster: 3660-size or smaller motor with the KV <3000KV

Resistance: 0.0007ohm
Battery: 2-3S Lipo/4-9Cells NiMH
BEC Output: 5.8V/3A (Switch mode)
Dimensions/Weight: 51.5x68.5x38.5mm/76g

Package Included:
1 x SURPASSHOBBY KK 3660 Brushless Motor
1 x SURPASSHOBBY Waterproof 60A ESC
1 x English Manual
