Speedybee MARK4 7-inch Carbon Fiber Penetration Machine Frame FPV For 2806 Motor Flying Tower Item NO.: F52012

Speedybee MARK4 7-inch Carbon Fiber Penetration Machine Frame FPV For 2806 Motor Flying Tower

Product parameters

MAK 7-inch product specifications maximum support blade: 7-inch wheelbase: 295MM

Size: 193 * 223MM
Weight: 128g

Bottom plate thickness: 2.5mm
Top plate thickness: 2.5mm
Clamp plate thickness: 2MM
Arm thickness: 5MM
Protective frame thickness: 2MM

Features of MAK4 series products

MAK4 fancy rack, a lighter and better performing rack that is more convenient to install. ☑ Smooth flight, FPV shooting is easier and more elegant.

The H-shaped structure does not affect the flight experience at all. On the contrary, compared to the X-shaped structure, the arm is shorter, lighter in weight, and has higher arm strength

The H-shaped layout provides more installation space in the middle section of the aircraft compartment, lower center of gravity, and more stable flight. The installation size of the FPV lens is 19MM wide, suitable for micro lenses such as the Flathead Brother second-generation Thundersnake MICRO/Toothless Baby MICRO

There are two types of flight control installation positions, 30.5 * 30.5 and 20 * 20, reserved in the front and back of the V aircraft compartment, which are suitable for the installation of various flight control equipment.

Fixed motor installation hole spacing: 16 * 16/16 * 19/19 * 19MM, all compatible

The edges and corners of the entire machine have been chamfered, and the workmanship is fine and the structure is reasonable. Of course, there are also customized thickened aluminum pipes to ensure the strength of the frame.
