Home>Consumer Electronics>R8XM Receiver Built-in Power Battery Voltage Return Mini 8-channel Receiver Vehicle Model T8S

R8XM Receiver Built-in Power Battery Voltage Return Mini 8-channel Receiver Vehicle Model T8S Item NO.: F51757

US$ 10.65

Quantity: Stock ( 9999999 )

Estimate Shipping Cost

Product Name	R8XM Receiver Built-in Power Battery Voltage Return Mini 8-channel Receiver Vehicle Model T8S
Item NO.	F51757
Weight	0.015 kg = 0.0331 lb = 0.5291 oz
Category	Consumer Electronics
Creation Time	2024-01-22

Product Name: R8XM
Weight: 3 grams (4 grams of cable)
Size: 22*17mm
Antenna length: 90mm
Channel: 8 channels
Operating voltage: 3-6VDC
Working current: 40mA±5mA@5V
Signal: SBUS/PPM
Spread spectrum mode: FHSS 67 channel pseudo random frequency hopping
Frequency: 2.4GHzISM band (2400MHz~2483.5MHz)
Applicable models: Traverser/helicopter/fixed wing/glider/multi-rotor/car/ship/Mecha and all models
(To be used with flight control)
Return voltage range: 2S-6S(7.4-25.2V)
Return information: Signal, signal strength RSS I, receiver voltage, power battery voltage
Control distance: the air distance is 4000 meters, the actual control distance is related to the flight environment

Compatible remote control: T8FB/T8S/RC8X/RC6GSV 3/RC4GSV 3/RC6GSV 2/RC4GSV 2/RC6GS/RC4GS
