iFlight XING-E 3314 FPV Model Motor High Performance Brushless Motor 900KV Item NO.: F52081

Sold (5)

US$ 39.01

Quantity

Quantity: Stock ( 19999997 )

Estimate Shipping Cost

Product Name	iFlight XING-E 3314 FPV Model Motor High Performance Brushless Motor 900KV
Item NO.	F52081
Weight	0.145 kg = 0.3197 lb = 5.1147 oz
Category	Consumer Electronics
Creation Time	2024-04-13

1pcs IFlight XING-E 3314 Cinelifter Motor 900KV 6S LiPo for FPV Freestyle Long Range Cinelifter Drones DIY Quadcopter Parts

Specification

Model: XING-E 3314 Motor

KV: 900KV

Weight(included wire): 120g

**Dimension: φ38.6*29.8mm**

Interphase Resistance: 48.1mΩ

Input Volts: 24V

Peak Current: 58.48A

Max Watt: 1366.1W

**Mounting Holes: 19*19 φ3mm**

Shaft Diameter: 5mm

Shaft Protruding Length: 15mm

Lead: 400mm/16AWG

Magnet: N52H Curved

Configuration: 12N14P

**Bearing Specification: φ11φ55**

Winding: Single Strand copper winding

Packing List

1 x XING-E 3314 900KV Brushless Motor

**4 x M3*10 screws**

1 x M5 Flange Nut
