QWinOut Xy-4 Quadcopter RC Drone Frame Kit with F4 OSD Flight Control + 1806 2500KV Motor+ 4032 Propeller (No Camera, video transmission)

US$ 116.39

model

Estimate Shipping Cost

Detail
- Product Name: QWinOut Xy-4 Quadcopter RC Drone Frame Kit with F4 OSD Flight Control + 1806 2500KV Motor+ 4032 Propeller (No Camera, video transmission)
- Item NO.: F46124-H /I/J/K
- Weight: 0.29 kg = 0.6393 lb = 10.2294 oz
- Category: DIY RC Drone Accessories > Receiver
- Brand: QWINOUT
- Creation Time: 2022-02-15
Please note: Already assembled，Camera, video transmission, and antenna are not included

XY-4 Frame kit
Rack Type: HX Type
Wheelbase: 175mm
Arm thickness: 3.5mm
The thickness of the rest of the board: 1.5mm
Colour: Black

Integrated 35A 4in1 ESC F4 OSD flight controller
Size: 32.5x32.5mm
Mounting hole: 25.5 x25.5mm
Weight: 7.3g
CPU: STM32F411CEU6 (100MHz)
Microprocessor: MPU6000 (SPI)
Firmware: Betaflight JHEF411
BEC output (two): 9V / 2A, 5V2.5A
Receiver; Sbus, ibus, dsm2, dsmx, TBS (uart2)
Black box: 8mb
Built-in current sensor
Input voltage: 2-6S Lipo
ESC current: 35A
Firmware: BLHELI_S GH-30.hex

Paddle
Product name: 4032
Size: 4*3.2 inch 3 blades
Pitch: 3.2 inches
Hub size: 5mm
Weight: 3.09g
Material: PC
Center Thickness: 6.5mm
Diameter: 102.2mm
Maximum blade width: 14.25mm

Motor
Specification: 1806
KV: 2500
Shaft diameter: 5mm
Motor weight: 21.2g
Support voltage: 2-4s
