Copy| Product Name | IFLIGHT XING-E 5215 Motor 300KV/500KV For X-Class Quadcopters FPV Drone Parts |
| Item NO. | F54810-D1 F54810-D2 F54810-D1-4 F54810-D2-4 |
| Weight | 0.4 kg = 0.8818 lb = 14.1096 oz |
| Category | DIY RC Drone Accessories > Motor |
| Brand | iFlight |
| Creation Time | 2025-11-10 |
（iFlight）XING-E 5215 FPV300KV/500KV Motor For Drone Toy
Description
Meet the latest high-performance motor from Xing-E—engineered to shatter limits and redefine reliability for large drone builds. Leveraging cutting-edge
technological advancements, this motor delivers consistent, dependable performance, making it a standout choice for enthusiasts and professionals focused
on bigger X-Class quadcopters.
Specifications
Model: XING-E 5215 Motor
KV: 300KV / 500KV
Weight(included wire): 344.5g
Dimension: φ60.2*65mm
Interphase Resistance: 49.57mΩ / 25.58mΩ
Input Volts: 12S / 8S
Peak Current: 71.07A / 106.49A
Max Watt: 3361.83W/ 3294.62W
Shaft Diameter: 6mm
Shaft Protruding Length: 26mm
Lead: 600mm/14AWG
Magnet: N52H-T
Configuration: 12N14P
Mounting holes: 30*30 φ4mm
Rotor Specifications: Segmented Bell
Bearing Specification: φ15*φ6*5
Winding: Multi-Strand copper winding
