(HobbyWing)EZRUN MAX8 G2 160A Sensing brushless ESC For 1/8th Truck/Monster Truck

(HobbyWing)EZRUN MAX8 G2 160A Sensing brushless ESC For 1/8th Truck/Monster Truck Item NO.: F47606

Write a Review
US$ 127.34
US$ 141.49 Save US$ 14.15 (10% Off)
Quantity

Copy and share this link on social network or send it to your friends

Copy
  • (HobbyWing)EZRUN MAX8 G2 160A Sensing brushless ESC For 1/8th Truck/Monster Truck
Product Name (HobbyWing)EZRUN MAX8 G2 160A Sensing brushless ESC For 1/8th Truck/Monster Truck
Item NO. F47606
Weight 0.215 kg = 0.4740 lb = 7.5839 oz
Category Toy and Hobbies > RC Car & Boat
Brand Hobbywing
Creation Time 2022-06-16

(HobbyWing)EZRUN MAX8 G2 160A Sensing brushless ESC For 1/8th Truck/Monster Truck

Product Description:

Brand:HobbyWing
Specifications

Product Name: EZRUN MAX8 G2

Type:

Scale :1/8th

Brushed/Brushless: BL

Sensored/Sensorless: SD

Waterproof: Yes


Specifications

 Cont./Peak Current :160A/1050A

Input Voltage: 3-6S Lipo

BEC Output: 6V/7.4V/8.4V adjustable, continuous current 6A (Switch-mode)


Wires & Connectors:

 Input Wires: Red-10AWG-150mm*1/Black-10AWG-150mm*1/Red-10AWG-200mm*1

Output Wires

Input Connectors: XT90

Output Connectors: 6.5 Bullet Connectors (Female)

(Note: All the wire lenath above is the oriainal lenath not the lenath you see from the outside.


Fan:

Size :30x30x10mm

Voltage Range: 6-8.4V

Powered by :BEC


ESC Programing via :

SET Button on ESC Not Supported

LED Program Box Supported

LCD Program Box Supported (G2)

OTA Programmer Supported

Program Port PRG/Fan Port


Firmware :

Firmware Upgrade Supported

Size &Weight:

Size: 60mm*48mm*40.5mm

Weight :192g


Applications:

Motors :Sensored brushless motors/Sensorless brushless motors

Vehicles: 1/8th Truck, Monster Truck

KV Rating/T Count With 4S Lipo: KV≤3000;

With 6S Lipo: KV≤2400 4278 size motor


The package contains:
ESC*1
