Home>DIY RC Drone Accessories>Motor>Happymodel SE0702 1S Brushless Motor 23000KV 26000KV 28000KV 1mm Motor Shaft For FPV Drone
Happymodel SE0702 1S Brushless Motor 23000KV 26000KV 28000KV 1mm Motor Shaft For FPV Drone

Happymodel SE0702 1S Brushless Motor 23000KV 26000KV 28000KV 1mm Motor Shaft For FPV Drone Item NO.: F44841 F44841-D2 F44841-D3

Write a Review
US$ 5.23
US$ 6.15 Save US$ 0.92 (15% Off)
Version
26000KV 23000KV 28000KV
Quantity

Copy and share this link on social network or send it to your friends

Copy
  • Happymodel SE0702 1S Brushless Motor 23000KV 26000KV 28000KV 1mm Motor Shaft For FPV Drone
Product Name Happymodel SE0702 1S Brushless Motor 23000KV 26000KV 28000KV 1mm Motor Shaft For FPV Drone
Item NO. F44841 F44841-D2 F44841-D3
Weight 0.01 kg = 0.0220 lb = 0.3527 oz
Category DIY RC Drone Accessories > Motor
Brand Happymodel
Creation Time 2023-08-08

Happymodel SE0702 1S Brushless Motor 23000KV 26000KV 28000KV 1mm Motor Shaft For FPV Drone

The lightest brushless motors all over the world , the weight is only 1.46gram.
You can build an extreme weight tiny whoop with this amazing motors.
Specifications:
Brand Name: Happymodel
Mode: SE0702
KV option: KV23000 or KV26000 KV28000
Configu-ration:9N12P
Stator Diamter:7mm
Stator Length:2mm
Shaft Diameter:Φ1mm
Motor Dimension(Dia.*Len):Φ9.5mm*14mm
Weight(g):1.46g
No.of Cells(Lipo):1S only


The packaging includes:
Motor * 1


Happymodel SE0702 Brushless motor Bench data
No-load voltage No-load
current
No-load Speed KV Voltage
(v)
Current
(A)
Thrust
(g)
Efficiency
(g/w)
Power
(w)
Propeller
Happymodel SE0702 KV26000
2 0.35 51070 25535.0 3.7 0.98 8 2.206 3.626 HQPROP
31MM Bi-blade propeller
3.7 1.49 11.9 2.159 5.513
3.7 1.99 15.6 2.119 7.363
3.7 2.5 19.6 2.119 9.25
3.7 2.8 21.7 2.095 10.36
