Home>RC Toy Drone>Happymodel>HappyModel Mobula7 HDZERO ELRS X2 F411 12A RunCam Nano HDZero 200mW EX1102 KV9000 ELRS 2.4G SPI 2-3S 75mm HD FPV BWhoop
HappyModel Mobula7 HDZERO ELRS X2 F411 12A RunCam Nano HDZero 200mW EX1102 KV9000 ELRS 2.4G SPI 2-3S 75mm HD FPV BWhoop

HappyModel Mobula7 HDZERO ELRS X2 F411 12A RunCam Nano HDZero 200mW EX1102 KV9000 ELRS 2.4G SPI 2-3S 75mm HD FPV BWhoop Item NO.: F48356

US$ 237.10 ~ US$ 263.44
Quantity 0-3 4-50 51-100
Discount 0% OFF 5% OFF 10% OFF
Price US$ 263.44 US$ 250.27 US$ 237.10
Quantity
Estimate Shipping Cost
Add to Cart

Adding to cart succeed

0 item(s) in cart, Subtotal: US$ 0

Continue Shopping View My Cart

Copy and share this link on social network or send it to your friends

Copy
  • HappyModel Mobula7 HDZERO ELRS X2 F411 12A RunCam Nano HDZero 200mW EX1102 KV9000 ELRS 2.4G SPI 2-3S 75mm HD FPV BWhoop
Product Name HappyModel Mobula7 HDZERO ELRS X2 F411 12A RunCam Nano HDZero 200mW EX1102 KV9000 ELRS 2.4G SPI 2-3S 75mm HD FPV BWhoop
Item NO. F48356
Weight 0.12 kg = 0.2646 lb = 4.2329 oz
Category RC Toy Drone > Happymodel
Brand Happymodel
Creation Time 2022-09-02

HappyModel Mobula7 HDZERO ELRS X2 F411 12A RunCam Nano HDZero 200mW EX1102 KV9000 ELRS 2.4G SPI 2-3S 75mm HD FPV BWhoop


This FPV Racing whoop is equipped with built-in ExpressLRS capabilities, as well as a RunCam HDZero Nano Camera and the all-new HDZero Whooop VTX for a smooth and powerful flight.

Specifications:
Brand Name: HDZERO and HappyModel Co-branded
Model: Mobula7 HDZERO
Frame wheelbase: 75mm
Weight: 41gram without battery
Size: 98mm*98mm*50mm
Radio Link System required: ExpressLRS 2.4GHz TX module 2.0 ELRS firmware
Compatible with 2S-3S Lipo battery or Lihv battery
Recommend Battery: 2S 300/350/450/550/650 mAh
3s 300/350/450 mAh
Battery Plug: XT30
Battery holder tray size: 17mm*13mm


Flight controller

MCU:STM32F411CEU6 (100MHZ, 512K FLASH)
Sensor: MPU-6000(SPI connection)
Mount pattern: 25.5×25.5 M2
Power supply: 2-4S Lipo battery
Built-in 12A Blheli_s ESC each
Built-in Betaflight OSD(SPI Control)
Built-in SPI ExpressLRS 2.4GHz receiver
Built-in 5V 1A BEC
Flight controller firmware target: CRAZYBEEF4SX1280
Voltage meter scale setting 110
Amperage meter scale setting 470

Onboard 4in1 ESC

MCU upgraded to EFM8BB21
Power supply: 2-4S LiPo/LiPo HV (7v/17v)
Currents: 12A continuous peak 15A (5 seconds)
Support BLHeliSuite programmable
Factory firmware: F_H_40_REV16_8.HEX
Default protocol: DSHOT150/DSHOT300/DSHOT600

Onboard SPI ExpressLRS 2.4GHz Receiver

Packet Rate option: 25Hz/50Hz/150Hz/250Hz/500Hz
RF Frequency: 2.4GHz
Antenna plug: IPEX
Telemetry output Power: <12dBm
Receiver protocol:  SPI ExpressLRS
Could bind with ELRS V2.0 firmware TX module

Camera
RunCam Nano HDZero

Model: Racer
SKU: HDZ3203
Lens: FOV D150 degree
Power: 450mA@3.3v
Digital: 1280*720@60fps

VTX
HDZero Whoop(TX5S.1)

Model: HDZero Whoop
SKU: HDZ3110
Frequency: 5.8G
Resolution Default: 1280*720@60fps
RF power: 25mw/200mw
RF Connector: U.FL
Interface: 4 lane MIPI CSI YUV422
Video Connector: 20 Position 0.30mm Pitch
Size: 32.5mm x 32.5mm x 7mm
Weight: 5.4g
Power:  410mA@12V
Mounting: 25.5mm*25.5mm,M2 clearance hole

Motor

Mode: EX1102 KV9000
Configu-ration:9N12P
Stator Diamter:11mm
Stator Length:2mm
Shaft Diameter:Φ1.5mm
Motor Dimension(Dia.*Len):Φ13.5mm*16mm
Weight(g):2.8g
No.of Cells(Lipo):2S-3S

Propeller

Brand Name: NewBeeDrone
Model: AZI
Size: 40mm
Tri-blade
Color: transparent
Shaft size: 1.5mm
