Home>DIY RC Drone Accessories>ESC>FEICHAO Two-way ESC 12A/20A/30A/40A/50A/60A/80A 2S-3S Speed Controller w/ Brake w/ Welded 3.5 Banana Head + T Plug/XT60 for Remote Control Boat Wind Boat

FEICHAO Two-way ESC 12A/20A/30A/40A/50A/60A/80A 2S-3S Speed Controller w/ Brake w/ Welded 3.5 Banana Head + T Plug/XT60 for Remote Control Boat Wind Boat Item NO.: F43564 - F43577

Sold (6)

US$ 3.26 ~ US$ 3.62

Quantity	0-3	4-50	51-100
Discount	0% OFF	5% OFF	10% OFF
Price	US$ 3.62	US$ 3.44	US$ 3.26

Version: w/ T plug w/ XT60

Type: 12A 2S-3S 20A 2S-4S 30A 2S-4S 40A 2S-6S 50A 2S-6S 60A 2S-6S 80A 2S-6S

Quantity: Stock ( 139999980 )

Estimate Shipping Cost

Product Name	FEICHAO Two-way ESC 12A/20A/30A/40A/50A/60A/80A 2S-3S Speed Controller w/ Brake w/ Welded 3.5 Banana Head + T Plug/XT60 for Remote Control Boat Wind Boat
Item NO.	F43564 - F43577
Weight	0.036 kg = 0.0794 lb = 1.2699 oz
Category	DIY RC Drone Accessories > ESC
Brand	FEICHAO
Creation Time	2021-04-24

FEICHAO Two-way ESC 12A 2S-3S Speed Controller w/ Brake w/ Welded 3.5 Banana Head + T Plug for Remote Control Boat Wind Boat

product information:

Bidirectional 20A 2-4S UBEC 2A 5V

Bidirectional 30A 2-4S UBEC 2A 5V

Bidirectional 40A 2-6S UBEC 3A 5V

Two-way 50A 2-6S UBEC 5A 5V

Bidirectional 60A 2-6S UBEC 5A 5V

Bidirectional 80A 2-6S UBEC 5A 5V

This product adopts imported components and is tested at full power before leaving the factory.
Can be used for vehicles, boats, underwater propellers.
Two-way 1:1 power output, without brakes, direct reverse, fast corresponding speed and good control linearity.
No need to calibrate the throttle stroke, plug and play.
This product contains UBEC output.

1. Optimize the position of the neutral point of the throttle to ensure that when the player uses dual ESCs, the two ESCs are always activated.

2. Optimized the start mode to make the throttle linearity more delicate and effectively reduce the stall phenomenon when the motor starts.

3. The brake function is added, giving customers more choices.

Remarks:

1. When using this product, the remote control throttle stick must be in the middle position, otherwise the ESC cannot be started.

2. This product does not need to calibrate the throttle stroke. After the ESC starts, if the motor starts to rotate, you can use the remote control throttle fine-tuning to stop the motor.
