5 Port 10/100 / 1000Mbp Industrial Ethernet Switch, Gigabit Network Switch, DIN Rail Type Lan Network Adapter, Signal Booster Item NO.: F44633

US$ 23.34

Quantity: Stock ( 9999999 )

Estimate Shipping Cost

Product Name	5 Port 10/100 / 1000Mbp Industrial Ethernet Switch, Gigabit Network Switch, DIN Rail Type Lan Network Adapter, Signal Booster
Item NO.	F44633
Weight	0.515 kg = 1.1354 lb = 18.1661 oz
Category	Consumer Electronics > Computer Accessories
Brand	DIEWU
Creation Time	2021-09-16

5 Port 10/100 / 1000Mbp Industrial Ethernet Switch, Gigabit Network Switch, DIN Rail Type Lan Network Adapter, Signal Booster

Design highlights
Supports DC 5 ~ 58V input range;
Industrial-of;
Integrated loop indicator;
Innovative design, metal housing
Product specification
Model number
TXE043
Chipset
IP185GHI
Port number
5-port 10/100 / 1000M MDI-MDIX RJ45
Standard
IEEE 802.3 、 IEEE 802.3u 、 IEEE 802.3x 、 IEEE 802.3az 、 IEEE 802.3ab
Media network
10Base-T, cat3 or above UTP, 100 / 1000Base-Tx, cat5 or above UTP
Data speed
10/100 / 1000M
Of the rate
10 Mbps / 14,880 pps 100 Mbps / 148,800 EPA 1000Mbps / 1488000pps
LED indicator
Green: 10 / 100Mbps (link / action), Orange: 1000Mbps (link / action), power, loop indicator
Dimension
118 * 80 * 30mm
Input power
DC5V-58V
Energy consumption
Max2.5W
Environment
Operating temperature: -40 ℃ -85 ℃
Corresponding humidity: 10% -90% (non-condensing)
Storage temperature: -40 ℃ -85 ℃
Corresponding humidity: 5% -90% (non-condensing)
