2.4GHZ Annular Ring Coupler 3Db Electric Bridge Directional Coupler Frequency Range 2.3GHZ~2.5GHZ with SMA Female Connector

Description.

This ring coupler is also called hybrid ring, which is a kind of power divider, you can also consider this as a directional coupler with 3DB coupling. Generally, when measuring the main signal, take the 3DB signal out as a test, because there is a certain degree of isolation between the two channels, so the measurement will not have too much impact on the main signal products

Parameter indicators.

1、Frequency range 2.3GHZ~2.5GHZ;

2、S21>-3.8dB;

3、S11<-15dB;

4、S22<-15dB;

Product size: 50*50MM without SMA

SMA outer screw inner hole

Product weight: 12g
