iFlight XL7 V3 True X 7 inch 294mm Low Ride FPV Freestyle Frame Kit Carbon Fiber for RC Racer Quadcopter DIY Drone

Copy and share this link on social network or send it to your friends

Copy

iFlight XL7 V3 True X 7 inch 294mm Low Ride FPV Freestyle Frame Kit Carbon Fiber for RC Racer Quadcopter DIY Drone Item NO: F25121

US$ 41.99
Sold Out
  • iFlight XL7 V3 True X 7 inch 294mm Low Ride FPV Freestyle Frame Kit Carbon Fiber for RC Racer Quadcopter DIY Drone
Product Name iFlight XL7 V3 True X 7 inch 294mm Low Ride FPV Freestyle Frame Kit Carbon Fiber for RC Racer Quadcopter DIY Drone
Item NO F25121
Weight 0.33 kg = 0.7275 lb = 11.6404 oz
Category DIY RC Drone Kit / RC Drone Accessories > Iflight 12% off
Brand iFlight
Creation time 2018-06-25

iFlight XL7 V3 True X 7 inch 294mm Low Ride FPV Freestyle Frame Kit Carbon Fiber for RC Racer Quadcopter DIY Drone


Descriptions:

This freestyle frame gives you ultimate control over weight distribution and CoG by not only allowing the use of M3x30mm standoff but also offering a reversible build orientation for a true mid-mount set up.

Features:

- Chamfered Edge High quality Pure 3K carbon plate
- Adjustable camera placement
- Top mounted battery for optimal CG
- True X frame design
- Replaceable 4mm arms and plates
- High quality 3K full carbon
- Grade 12.9 Black Nickel Plating high quality screw hardware
- Compact design

Specifications:

- Type: 7" Freestyle frame
- Frame wheelbase: 295mm
- Dimensions :208mm x 208mm(body dimension)
- Frame weight:135g approx
- Motor c-clip hole: 8mm
- Standoff Height: 30mm
- 4mm arms,1.5mm vertical side plates
- 2mm top,upper&bottom plate
- Mounting Holes: 30.5*30.5mm
- Carries: 1300-1500mAh lipo + GoPro Session

Recommended parts(not included):

- Flight controller: RevoBee  F4 Compatible controller
- Motor: iPower the Ion/Tachyon 2207 Motor 1600/1750kv / XRotor 2405 1800kv
- Propeller: 7 inch propeller
- Camera: FPV cameras 28mm wide
- VTX: 600mW 48Ch Transmitter
- Battery: 4s Lipo battery

Package Included:

1pc * iFlight XL7 V3 True X 7 inch Frame Kit


2019-05-10

Christian

Good frame.
Oerfect for long range
