SkyRC Q200neo Charger SK-100197 AC200W DC400W 4 Output Ports AC/DC Smart Charger

US$ 167.70

Version

Estimate Shipping Cost

Detail
- Product Name: SkyRC Q200neo Charger SK-100197 AC200W DC400W 4 Output Ports AC/DC Smart Charger
- Item NO.: F50974-D1/F50974-D2/F50974-D3
- Weight: 0.71 kg = 1.5653 lb = 25.0445 oz
- Category: DIY RC Drone Accessories > Charger
- Creation Time: 2023-10-10
- SkyRC Q200neo Charger SK-100197 AC200W DC400W 4 Output Ports AC/DC Smart Charger
SkyRC Q200neo Charger SK-100197 AC200W DC400W 4 Output Ports AC/DC Smart Charger

Specifications:

Brand Name: SKYRC

Model: SK-100197 Q200neo

Power

DC Input Voltage: 10-30V

AC Input Voltage: 100-240V 50/60HZ

Charge Wattage:

AC: 200W MAX

DC: 400W MAX

Discharge Wattage:

Main port: 5W;

Balance port: 25W MAX(Lipo 6s)

20W USB-C Power Delivery:

QC3.0: 5V=3A, 9V=2A, 12V=1.5A 18W
PD: 5V=3A, 9V=2.2A, 12V=1.67A 20W

DC power supply

Output Voltage: 1.0-30.0V

Output Current: 0.1-10.0A

Output Power: Max. 100W single port

Battery Types/Cells:

LiPo/LiHV/LiFe/LiIon: 1-6cells

NiMH/NiCd: 2-15cells

Pb: 3S/6S/12S

Charge current

LiPo/LiFe/LiIon/LiHV/NiMH/NiCd/Pb：0.1-10.0A

Discharge current

LiPo/LiFe/LiIon/LiHV/NiMH/NiCd/Pb：0.1-2.0A

Balance current

LiPo/LiFe/LiIon/LiHV：800mA MAX

Operation

LiPo/LiFe/LiIon/LiHV: Balance, Charge, Discharge, Storage, Parallel

NiMH/NiCd: Charge, Cycle, Re-peak, Discharge

Pb: Normal, AGM Charge, Cold Charge, Discharge

Working and Storage

Operating temperature: 0℃-40℃

Working humidity: 0%-75%

Storage temperature: -10℃-70℃

Storage humidity: 0%-75%

Case Material: PC-ABS V0

Case Size: 123*119*78mm

Weight: 680g
