| Product Name | RunCam Hybrid 4K HD Mini FPV Camera Dual Lens Wide Angle HD Recording FOV 145 Degree SONY 8MP Sensor For FPV RC Racing Drone Cinewhoop |
| Item NO. | F32803 |
| Weight | 0.083 kg = 0.1830 lb = 2.9277 oz |
| Category | DIY RC Drone Accessories > Camera |
| Brand | RunCam |
| Creation Time | 2019-10-17 |
Description:
Brand : RunCam
Item name : hybrid
Color : Black
| HD sensor | for SONY 8MP |
| Analog sensor | for SONY 1.3MP |
| Field of View (FOV) | HD Recording FOV 145°(FPV FOV: 150° 4: 3) |
| Video Resolution | 4K 30fps / 2.7K 60fps / 2.7K 50fps / 1080P 120fps / 1080P 100fps / 1080P 60fps / 1080P 50fps |
| Video File Format | MP4 |
| TV Mode | NTSC (720*480)/PAL (720*576) Switchable |
| Interface | HD supports UART remote control; Analog supports UART fimrware update. |
| Max Micro SD CardSupported | Up to 128G. U3 recommended (2.7K60/1080P120 requires U3 or above; other solutions require U1 or above) Please make sure that the file format of the SD card is FAT32, otherwise, it will easily cause errors. |
| Mounting Hole Distance | 20*20mm |
| PCB Size | 29*29mm |
| Lens Module Size | 19*25mm |
| Lens Specs | HD M10 Analog M8 |
| Power Input | DC 5-20V (Non-direct power supply from 4s battery or above. Powered direcly with battery will generate surges and burn the camera.) |
| Working Current | 480mA 5V / 140mA 12V |
| Weight | 18g |
-True 145° HD Recording & 6ms FPV Latency
-Single board Supporting Start/Stop Recording via UART Control
-HD Recording supports QR Code Setup Analog FPV supports Firmware Update
Package:
1x RunCam hybrid Camera
1x Plastic cover
1x 3PIN FPV silicone cable(male)
1x 3PIN FPV silicone cable(female)
1x Set of M2 screws
