JMT Acrylic Plate Car Chassis Frame Self-balancing Mini Two-drive 2 Wheels 2WD DIY Robot Kit 176*65mm Technology Invention Toys Item NO.: F23639

Sold (66)

US$ 13.84

Quantity: Stock ( 9999933 )

Estimate Shipping Cost

Product Name	JMT Acrylic Plate Car Chassis Frame Self-balancing Mini Two-drive 2 Wheels 2WD DIY Robot Kit 176*65mm Technology Invention Toys
Item NO.	F23639
Weight	0.4884 kg = 1.0767 lb = 17.2278 oz
Category	Toy and Hobbies > Chassis Robot
Brand	JMT
Creation Time	2018-01-07

JMT Acrylic Plate Car Chassis Frame Self-balancing Mini Two-drive 2 Wheels 2WD DIY Robot Kit 176*65mm Technology Invention Toys

Total Size: about 176 * 65mm

Acrylic plate size : 120 * 60 * 4mm

Height: about 65mm

Motor type: 25 Model Geared Motor

Number of motors: 2

Motor Parameters: Rated voltage: 6v, no-load speed : 133RPM, reduction ratio: 1:45, load current: about 75mA, Stall current: approximately 1.3A, total length: about 52MM, diameter: 25mm, shaft length : 12mm, shaft diameter : 4mm (D word pin side shaft), weight: about 90.24g

Tire Parameters: Diameter 65mm, width of 26mm, the tread rubber material, plated plastic wheels

Body material: 4mm transparent acrylic plate

Weight: about 396 grams
