ISDT ESC70 WP 1080 70A Electronic Speed Controller Brushed (2-3S) Motor ESC Waterproof XT60-Plug RC Car 1:10 1:8

ISDT ESC70 WP 1080 70A Electronic Speed Controller Brushed (2-3S) Motor ESC Waterproof XT60-Plug RC Car 1:10 1:8 Item NO.: F46283

Write a Review
US$ 23.74
Quantity

Copy and share this link on social network or send it to your friends

Copy
Product Name ISDT ESC70 WP 1080 70A Electronic Speed Controller Brushed (2-3S) Motor ESC Waterproof XT60-Plug RC Car 1:10 1:8
Item NO. F46283
Weight 0.07 kg = 0.1543 lb = 2.4692 oz
Category DIY RC Drone Accessories > ESC
Brand iSDT
Creation Time 2022-01-11

Model: ISDT ESC70

Continuous / peak current: 70 / 120a

Supported motor type: 540 / 550 / 775 brush motor

Applicable models: 1 / 8 or 1 / 10 models (parameters adjustable)

Battery type: 2 ~ 3S lipo or 6 ~ 9 cell NIMH

BEC output: 5V ~ 7.5V adjustable (step 0.1V)

Wire / plug: 1 6awg-200mm / no plug

Size: 38.6x31 6x17. 15mm (excluding wire)

Weight: electric regulator about 49G / switch about 4.5g


Product features


Waterproof design to adapt to various climatic environments (Note: wash and dry the electric regulator as soon as possible after water is injected to prevent oxidation of the plug)

● equipped with electronic switch + Bluetooth two in one - module, which can view the working status and set the operating parameters in real time through ISD go app

● with switch mode BEC, continuous current up to 3a, Voltage 5V to 7.5V, adjustable in 0.1V steps, can drive high-voltage steering gear


Adjustable output PWM frequency and synchronous freewheeling function provide better throttle linearity and temperature performance


● active braking function


Duo weight protection function: battery low voltage protection, over temperature protection, accelerator out of control protection, BEC overvoltage and undervoltage protection


● stepless adjustment of throttle and brake curve


● customizable start tone


. OTA upgrades firmware and updates functions in time


Ramp anti-skid locking function designed for climbing car


Package included:

1pcs new ISDT 70A ESC
