Hobbywing Platinum 25A V4 3-6S Lipo / Platinum 40A V4 ESC 3-4S Lipo Brushless ESC Speed Controller for RC Helicopter 450-480 Item NO.: F22270-F22271

Sold (1)

US$ 27.52 ~ US$ 30.58

Quantity	0-3	4-50	51-100
Discount	0% OFF	5% OFF	10% OFF
Price	US$ 30.58	US$ 29.05	US$ 27.52

Type: PLATINUM-40A-V4 PLATINUM-25A-6S-V4

Quantity: Stock ( 19999997 )

Estimate Shipping Cost

Feature
Excellent Motor Governing Speed
High Voltage Built-in BEC
DEO Technology
Reverse Brake
Multiple Protections include, ESC thermal,capacitor thermal.
A separate programming port for connecting the programmer on this ESC allows user to Program ESC

Product Name	Hobbywing Platinum 25A V4 3-6S Lipo / Platinum 40A V4 ESC 3-4S Lipo Brushless ESC Speed Controller for RC Helicopter 450-480
Item NO.	F22270-F22271
Weight	0.22 kg = 0.4850 lb = 7.7603 oz
Category	DIY RC Drone Accessories > ESC
Brand	Hobbywing
Creation Time	2017-09-03

Hobbywing Platinum 25A V4 3-6S Lipo / Platinum 40A V4 ESC 3-4S Lipo Brushless ESC Speed Controller for RC Helicopter 450-480

Description

1.High-performance microprocessor with the operating frequency up to 50MHz brings excellent compatibility (with most motors in the market) and high driving efficiency.

2.The maximum motor speed can reach 210000 RPM (for 2-poles), 70000 RPM (for 6-poles) and 35000 RPM (for 12-poles).

3.Multiple flight modes: Fixed Wing Airplane/ Heli with Governor Off/ Heli with Governor (Elf) / Heli with Governor Store.

4.Adjustable throttle range, compatible with various transmitters. It brings smooth, soft & linear speed adjustment and rapid throttle response.

5.Microprocessor powered by independent DC regulator has better anti-interference performance, which greatly reduces the risk of losing control.

6.Built-in high-efficient & high-power (switch mode) BEC can make the output voltage switched among 5.2V / 6.0V / 7.4V / 8.4V. (*For the specific output voltage, please refer to the parameter list below.)

7.Brand new governor program, easy to operate; and its excellent speed-governing effect can make big rotor blades more stable even under rapid load change.

8."Restart in auto rotation" can manually interrupt the auto rotation and quickly restart the motor to avoid crashes caused by incorrect operations.

9.Independent output port for RPM (that is: motor speed) signals.

10.Compatible LCD program box (*optional accessory), its simple and visual interface allows users to set/revise all the ESC parameters easily. (For detailed information, please refer to User Manual of LCD Program Box.)

11.Upgradeable firmware, you can upgrade the ESC after connected it to a PC via the USB cable on the program box.

12.The independent port, for connecting the program box and setting parameters, can also be the output port of the running status data of the ESC. When coordinating with the data transmission module, it can make the real-time data monitoring and logging possible.

13.Multiple protection features including input voltage abnormality protection/ low-voltage cutoff protection/ throttle signal loss protection effectively prolong the service life of the ESC.

Feature
Excellent Motor Governing Speed
High Voltage Built-in BEC
DEO Technology
Reverse Brake
Multiple Protections include, ESC thermal,capacitor thermal.
A separate programming port for connecting the programmer on this ESC allows user to Program ESC

Package
1x Hobbywing Platinum V4 25A/40A ESC
