FLYCOLOR BOOSTER Power 5-12S 80A Two-Way PWM One- Way Inductive / Non-inductive NO BEC Brushless ESC Underwater Remote Operated

US$ 41.63

Type

Estimate Shipping Cost

Detail
- Product Name: FLYCOLOR BOOSTER Power 5-12S 80A Two-Way PWM One- Way Inductive / Non-inductive NO BEC Brushless ESC Underwater Remote Operated
- Item NO.: F45358-D1 F45358-D2 F45358-D3
- Weight: 0.09 kg = 0.1984 lb = 3.1747 oz
- Category: DIY RC Drone Accessories > ESC
- Brand: Flycolor
- Creation Time: 2021-11-22
Underwater thruster diving booster power 5-12S/80A two-way ESC, inductive and non-inductive level control

● Four control methods can be selected (need to inform in advance, factory preset):

1) PWM speed control: the designated port is connected to the receiver (the receiver needs external BEC power supply), which can support the throttle signal with a refresh rate of up to 500Hz (Note: throttle signals >=500Hz are all non-standard throttle signals)

2) Switch control start: Two switches are connected to the designated port; when any one of the switches is closed, it means the first gear, and the current is limited to 13A; when two switches are closed at the same time, it means the second gear, and the current is limited to 20A (the current limit can be customized);

3) Voltage speed regulation:

Voltage speed regulation method 1: Connect a potentiometer greater than 10K to the designated port, and realize speed control according to the resistance change of the potentiometer;

Voltage speed regulation mode 2: External input 0-5V voltage to the designated port, according to the change of the external voltage, realize the speed control;

4) Power-on start: S pad and 5V pad are short-circuited and input high level (TTL level 3.3-5V) to realize immediate start after power-on;

Main features:

● ESC adopts powerful STM32F051 series MCU, ARM 32-bit Cortex core, working frequency 48MHz;

● Optimized firmware, compatibility is very good; no need to set up, very easy to use;

● Use Active Switch Continued Flow (ASCF) technology to achieve higher efficiency and significantly reduce ESC heating;

● Excellent cost control plan, high cost performance;

● Multiple protection functions to effectively protect the product;

● A variety of additional functions can be selected to meet the different expansion needs of users (need to be preset in advance);

● It can support the throttle signal with refresh rate up to 500Hz. (Throttle signals ≥500Hz are non-standard throttle signals)
