DIATONE MAMBA F722 MINI MK3 Flight Controller 40A Pro 3-6S  Flight Controller Stack MPU6000 F7 40A BLHELIS 4in1 ESC for FPV Drones

Note： Please pay attention to the version of the product you purchase

MAMBA STACK BASIC F722 MINI MK3 40A 6S 8BIT

Update

• Add I2C function

• When you connect the USB, the receiver and OSD settings can be saved

• The pad area of the Mini flight controller (20×20) increased by 140%

• LED signal selection (when Mamba Led sys avaiable)

• BEC short circuit protection

• TVS instant high voltage protection 30V

• Upgrade the anti-interference cable

• Use Typec(Most)

Added

Add self-recovery insurance to the receiver's 5V power supply.
Increase the camera VCC power supply pad.
The standard flight controller (30.5×30.5) adds a spare pad.
Gyro uses an independent Low Dropout Regulator (Low Dropout Regulator) and reduces ripple interference.
Model: Mamba Stack Basic F722 Mini MK3 40A BLS 6S

FC Specifications
MAMBA Basic F722MINI MK3
MCU: 216MHz STM32F722RET6
GYRO: MPU6000
Barometer: Yes
OSD: Yes
Blackbox: 16M Flash Memory
Uarts: 6 Set
ESC Soft: Dshot300/600
ESC Telemetry: Yes
Power Led: Yes
LED Controller: BF LED
S/F.Port: Yes
RSSI: Yes
Buzz: Yes
Input: 2~6S Lipo (8.4~25.2V)
TVS Protection: Yes
BEC:3.3V 0.5A&  5V 2.5A
MOUNTING: 20mm, M2

ESC Specifications（optional）

MAMBA F40_BLS MINI

INPUT VOLTAGE: 2~6S Lipo (8.4V~25V)
CONTINUE CURRENT: 40A×4
BURST CURRENT: 45A (10S)
BEC: No
Target:BLHeli_S CH40
SOFT: Dshot300/600
TVS Protection: Yes
MOUNTING: 20mm, M3/M2

MAMBA F40 MINI PRO
INPUT VOLTAGE: 2~6S Lipo (8.4V~25.2V)
CONTINUE CURRENT: 40A×4
BURST CURRENT: 45A (10S)
BEC: No
Target:MAMBA F40MINIPRO
SOFT: Dshot300/600/1200
TVS Protection: Yes
MOUNTING: 20mm, M3/M2


Supply :
High-Frequency 470uF/35V ×1
8pin sh1.0  ×2
16AWG 60mm ×2

AMASS Original XT60
