12 Port USB 3.0 PCI-E x4 Expansion Card Motherboard PCIE to 19Pin Connector PCI Express Riser Adapter Card for Video Capture

12 Port USB 3.0 PCI-E x4 Expansion Card Motherboard PCIE to 19Pin Connector PCI Express Riser Adapter Card for Video Capture Item NO.: F46440-D1 F46440-D2

Write a Review
US$ 69.69
US$ 81.99 Save US$ 12.30 (15% Off)
Color
12xUSB3.0 Ports 6xUSB3.0 3x19Pin
Quantity

Copy and share this link on social network or send it to your friends

Copy
Product Name 12 Port USB 3.0 PCI-E x4 Expansion Card Motherboard PCIE to 19Pin Connector PCI Express Riser Adapter Card for Video Capture
Item NO. F46440-D1 F46440-D2
Weight 0.2 kg = 0.4409 lb = 7.0548 oz
Category Consumer Electronics > Computer Accessories
Creation Time 2022-03-01

12 Port USB 3.0 PCI-E x4 Expansion Card Motherboard PCIE to 19Pin Connector PCI Express Riser Adapter Card for Video Capture


Features.

6-channel 12-port USB3.0 expansion card with 6 independent broadband, no sharing of broadband per channel, no speed compromise.

USB3.0 standard, transfer rate 5Gbps.

Support keyboard, mouse, printer, cooling fan, disk array and other external devices. Note: Does not support two devices docking.

Thickened standard PCI-E interface gold fingers and chassis directly connected to the motherboard, to increase the stability of the missing connection, there is no transmission line loss, direct exchange more quickly.

Only need the motherboard with PCI E X4/X8/X16 slots can be easily expanded and work properly. Note that you can not access the PCI interface.

High performance independent chip, each channel is equipped with a chip, each channel exclusive broadband to enhance transmission speed.

3 x 19pin Connector expansion.

Adopt high thermal conductivity alloy material heat sink and fan, which can efficiently dissipate the heat generated by the expansion card and make the expansion card work more stable.



Parameters.

Brand: XT-XINTE

Bus interface: PCI-EX4 (compatible with X8/X16/video card interface)

Expansion interface.

External USB3.0*6,Internal USB3.0*6 OR

External USB3.0*6,Internal 19Pinx3 optional

Operating environment: -50℃-70℃

Interface speed: 5Gbps

Product size: 120mm*155mm*98mm

Support system: XP Win7 Win8/8.1 Win10

Quantity: 1PC
