HGLRC HGLRC F4 V5PRO Flight Controller 5.8G 40CH 0/25/200/600mW Switchable FPV Transmitte w/5V BEC OSD PDB For FPV RC Drone Quadcopter
HGLRC F4 V5PRO Flight Controller 5.8G 40CH 0/25/200/600mW Switchable FPV Transmitte w/5V BEC OSD PDB For FPV RC Drone Quadcopter

HGLRC F4 V5PRO Flight Controller 5.8G 40CH 0/25/200/600mW Switchable FPV Transmitte w/5V BEC OSD PDB For FPV RC Drone Quadcopter Item NO: F22464-F22465

US$ 61.20
type:
HOLE INSIDE NEEDLE INSIDE
Shipping Cost:
Estimate Shipping Cost
Quantity:

Specifications
Product Name HGLRC F4 V5PRO Flight Controller 5.8G 40CH 0/25/200/600mW Switchable FPV Transmitte w/5V BEC OSD PDB For FPV RC Drone Quadcopter
Item NO F22464-F22465
Weight 0.1100 Kg
Category DIY RC Drone Kit / RC Drone Accessories > Flight Control
Brand HGLRC
Creation time 2017-09-20

Detail

HGLRC F4 V5PRO Flight Controller 5.8G 40CH 0/25/200/600mW

Switchable FPV Transmitte w/5V BEC OSD PDB For FPV RC Drone

Quadcopter


Specification:
Item name: F4 V5PRO Flight Controller 0/25/200/600mW Switchable FPV Transmitte w/ 5V BEC PDB
Chip: STM32F405RGT6 , dual open 8K, MPU6000-SPI connection
Built-in 5V / 3A BEC output
Direct welding ESC PDB
Built-in current sensor
FPV Transmitter: 0/25/200/600mW 40CH switchable tranmitter
Input voltage: 2-6S
Board thickness: 1.6MM
copper foil thickness: 3OZ * 4
Maximum current: 200A
Hole mounting size: M3 30.5 * 30.5mm
Weight: 13.5g

Feature:
Built-in BETAFLIGHT OSD to achieve remote control PID parameters
Buzzer / programming LED / voltage monitoring / BLHELI-S ESC programming;
Support SBUS / PPM / DSMX and other mainstream mainstream receiver;
Black box FLASH 16M large capacity storage

Package Included:
1 X Module
1 X Antenna

1 X XT60 connector
